/01 Equipment and features
Basic configuration
01
Powerful vacuum extraction pump 5,5 kW
02
Cyclone separator with quick-mountable exhaust HEPA 13 cartridge
03
Pulse jet filter cartridge cleaning system
04
Rotary valve for powder dosing made from AISI 316
05
Vibrating sieve with ultrasonic cleaning for larger sieving capacity
06
40l big powder collection bin
07
10l waste powder collection bin
08
Level switch in collection cyclone
09
Load cell equipped powder collection bins for weight measurement
10
Suction hose Ø 50mm
11
8" Color touch interface
12
Easily moved by forklift or crane
13
Explosion-proof
10
11
12
13

/02 Specifications
Technical specifications
Dimensions (L x W x H)
2000 mm x 1100 mm x 2080 mm
Compressed air (min - max)
6 bar / 87 PSI - 8 bar / 116 PSI
Inert gas
Ar, N2, 6 bar / 87 PSI - 8 bar / 116 PSI
Air consumption
150l/min (air/gas)
Power
3 x 230/400 V, 3/N/PE 50/60 Hz
Weight
850 kg
