/01 Equipment and features
Basic configuration
01
Big window for process monitoring
02
Heavy duty gloves for manual work
03
LED workspace illumination
04
Manual rotary table, Ø 600 mm + lock
05
Butterfly valve closed collection hopper
06
Manual blow off gun
07
Explosion-proof
08
Electronic control box for managing all the machine functions
09
Connection for dust extraction unit, Ø 50mm
10
Safety fixtures for safe work
06
07
08
09
10
/02 Specifications
Technical specifications
Dimensions (L x W x H)
1500mm x 1200mm x 2050 mm
Workspace (L x W x H)
850 mm x 900 mm x 1000 mm
Build plate volume (L x W x H)
400 mm x 400 mm x 400 mm
Load capacity
250 kg
Compressed air (min - max)
6 bar / 87 PSI - 8 bar / 116 PSI
Air consumption
600 l/min
Power
3 x 230/400V, 3/N/PE 50/60 Hz
Weight
700 kg
Download PDF datasheet
/03 Video presentation
Machines for metal 3D printed parts
