/01 Equipment and features
Basic configuration
01
Powerful vacuum extraction pump 5,5 kW
02
Cyclone separator with HEPA 13 cartridge
03
Pulse jet filter cartridge cleaning system
04
15, 40, 75l big powder collection bin
05
Powder weight measurement system
06
Easy to move on wheels
07
Low inert gas consumption
08
Suction hose Ø 50, Ø 76, Ø 120 mm
09
Lower consumption of inert gas
10
Optional ultrasonic 63 micro sieving
07
08
09
10
/02 Specifications
Technical specifications
Dimensions (L x W x H)
1300mm x 900mm x 1900 mm
Compressed air (min - max)
6 bar / 87 PSI - 8 bar / 116 PSI
Inert gas
Ar, N2, 6 bar / 87 PSI - 8 bar / 116 PSI
Air consumption
150l/min (air/gas)
Power
3 x 230/400V, 3/N/PE 50/60Hz 3 kW
Weight
500kg
