/01 Equipment and features
Basic configuration
01
Enclosed chamber for safe work
02
Air gun for cleaning
03
Window for process monitoring
04
LED workspace illumination
05
Servo-driven swivel arm, 210° rotation
06
Ø 1500 mm servo-driven rotary table on swivel arm, 0-5 RPM
07
Frequency regulated electro vibrator on rotary table
08
Butterfly valve operated collection hopper
09
12" Colour touch interface
10
Electronic control box for managing all the machine functions
11
Safety fixtures for safe manual and automatic operation
12
HEPA13 exhaust cartidges
13
ATEX certified (Ex protected)
10
11
12
13
/02 Specifications
Technical specifications
Dimensions (L x W x H)
3100 mm x 2300 mm x 3200 mm
Workspace (L x W x H)
2000 mm x 2000 mm x 2000 mm
Build plate volume (L x W x H)
1000 x 1000 x 1000 mm
Load capacity
1100 kg
Compressed air (min - max)
6 bar / 87 PSI - 8 bar / 116 PSI
Inert gas
Argon, Nitrogen - 8 bar / 116 PSI
Air consumption
700l/min (air), 700l/min (gas)
Power
3 x 230/400V, 3/N/PE 50/60 Hz
Weight
2300 kg
